Wrap Custom Indoor/Outdoor Ceiling Fan DC Motor- Brushed Satin Brass (MAD8530BS)
by Fanimation
Wrap yourself in style with this sophisticated ceiling fan from Fanimation. with many motor and blade finish combinations available, Wrap Custom is a versatile ceiling fan. LED and CCT Select Light kit, blades and motor sold separately. This ceiling fan is Damp Rated for indoor or outdoor use. It can also be controlled by using the Fanimation Wi-Fi fanSync application.
Product Specification
Item #
MAD8530BS
Dimensions
Height: 12.46"
Width: 44.00"
Length: 44.00"
Additional product details
Vendor Item #
MAD8530BS
Category
Fans
Subcategory
Ceiling Fans
Finish
Brass
Option
Energy Efficient
, Outdoor
, Damp Rated
Voltage
100-120
Number of Blades
3 Blades
Location Rating
Damp Rated
Wattage
8w
Category
Motor
Finish
Brushed Satin Brass
Option
Energy Efficient
, Outdoor
Family
Wrap Custom
Voltage
120 V
Air Flow CFM
7141
Air Flow Efficiency
200
Blade Pitch
Varied
Canopy
6.14 Dia x 2.55 H
Harmonized Codes
8414.51.3000
Light Kit Included
No
Motor Size
158 x 22
Motor Type
DC
Ship Carton Height
7.6
Ship Carton Length
16.34
Ship Carton Width
8.86
Ship Weight
14.99
Sold By
EA
Warranty
Limited Lifetime
Weight
12.13
Airflow Efficiency Low
404
Airflow Efficiency Medium
552
Avg Airflow Efficiency
211
Avg CFM Energy
5114
Avg Energy Use
24
Avg Estimated Yearly Energy Cost
7
Avg Estimated Yearly Energy Cost on HIGH
10
Cap Included
Yes
Carton Cubic Feet
0.64
Case Height
7.6
Case Length
16.34
Case Quantity
1
Case Weight Pounds
14.99
Case Width
8.86
CEC Uploaded
Yes
Ceiling To Blade Edge
11.83
Ceiling To Bottom (No Light Kit)
12.46
Ceiling To Bottom (With Light Kit)
13.05
CFM Low
728
CFM Medium
4359
Country of Origin
China
Current Draw High
0.49
Current Draw Low
0.04
Current Draw Medium
0.13
DOE Classification
LSSD
DOE-FTC Uploaded
Yes
Downrod Length
4.5
Energy Efficient
Yes
Exempt from DOE Procedure
No
Fan Energy Star 4
Yes
Housing Diameter
8.88
Included Control
TR305
Included Control Type
Handheld
Indoor
Yes
Leadwire
80
Location Rating
Damp Rated
Max Ceiling Slope
27
Max Length
60
Max Width
60
Motor Finish Method Type
Painted
Motor Reversible
Yes
Number of Blades
3
Number Of Speeds
16
Outdoor
Yes
Prop 65 Description
This product can expose you to chemicals including Lead which are known to the State of California to cause cancer and birth defects or other reproductive harm. for more information go to www.P65Warnings.ca.gov
Regulated Product
Yes
Reverse Switch Location
Control
RPM High
138
RPM Low
29
RPM Medium
88
Safety Rating
UL Approved, cUL Approved
Voltage Cycles
60 Hz
Watts High
36
Watts Low
2
Watts Medium
8
Manufactured By
Fanimation
Other Details:
- CONTROL: Includes a Wi-Fi receiver and TR305 handheld remote with two 3V CR2032 batteries - Push buttons control 16 variable fan speeds
- FINISH: Brushed Satin Brass ceiling fan motor from the Wrap Custom collection - Set of three Damp Rated blades available in multiple finishes (sold separately)
- Infinite light levels, color temperature, fan/light timer, powering on/off, and fresh air, reverse, home away, safe exit modes
- INSTALLATION: Mounts to flat or minimally sloped ceilings with the included 1-in diameter x 4.5-in length downrod.
- LIGHTING: 18-Watt dimmable LED light kit with Correlated Color Temperature (CCT) Select technology and opal frosted glass available for added versatility (light kit sold separately)
- LOCATION: This ceiling fan is Damp Rated for use in indoor and outdoor covered spaces exposed to moisture and humidity
- Optional downrods are available in lengths up to 72 inches to adjust the fans height between 7-ft to 9-ft from the floor, ensuring maximum airflow.
- POWER: The 16-speed, quiet and energy efficient DC motor can provide airflow up to 7,141 CFM
- SAVINGS: Features a reversible motor, allowing you to switch the direction of your fan?s rotation and create energy savings
- TECHNOLOGY: Includes fanSync Wi-Fi connectivity, allowing the fan to pair with most smart home devices
- WARRANTY: Limited lifetime
